(Getting Serious About) Numbers

Photo Credit: George M. Bergman, CC BY-SA 4.0, via Wikimedia Commons

William Kahan, creator of the IEEE-754 standard.

Turing Award Winner, 1989

I have a number in my head
Though I don’t know why it’s there
When numbers get serious
You see their shape everywhere

Paul Simon

One of the themes of this course will be shifting between mathematical and computational views of various concepts.

Today we need to talk about why the answers we get from computers can be different from the answers we get mathematically

– for the same question!

The root of the problem has to do with how numbers are manipulated in a computer.

In other words, how numbers are represented.

Representations

A number is a mathematical concept – an abstract idea.

God made the integers,
all else is the work of man.

Leopold Kronecker (1823 - 1891)

In a computer we assign bit patterns to correspond to certain numbers.

We say the bit pattern is the number’s representation.

For example the number ‘3.14’ might have the representation ‘01000000010010001111010111000011’.

For reasons of efficiency, we use a fixed number of bits for these representations. In most computers nowadays we use 64 bits to represent a number.

Let’s look at some number representations and see what they imply about computations.

Integers

Kronecker believed that integers were the only ‘true’ numbers.

And for the most part, using integers in a computer is not complicated.

Integer representation is essentially the same as binary numerals.

For example, in a 64-bit computer, the representation of the concept of ‘seven’ would be ‘0..0111’ (with 61 zeros in the front).

There is a size limit on the largest value that can be stored as an integer, but it’s so big we don’t need to concern ourselves with it in this course.

So for our purposes, an integer can be stored exactly.

In other words, there is an 1-1 correspondence between every (computational) representation and the corresponding (mathematical) integer.

So, what happens when we compute with integers?

For (reasonably sized) integers, computation is exact …. as long as it only involves addition, subtraction, and multiplication.

In other words, there are no errors introduced when adding, subtracting or multiplying integers.

However, it is a different story when we come to division, because the integers are not closed under division.

For example, 2/3 is not an integer. … It is, however, a real number.

Real Numbers and Floating-Point Representations

Representing a real number in a computer is a much more complicated matter.

In fact, for many decades after electronic computers were developed, there was no accepted “best” way to do this!

Eventually (in the 1980s) a widely accepted standard emerged, called IEEE-754. This is what almost all computers now use.

The style of representation used is called floating point.

Conceptually, it is similar to “scientific notation.”

\[123456 = \underbrace{1.23456}_{\text{significand}}\times {\underbrace{10}_{\text{base}}}^{\overbrace{5}^{exponent}}\]

Except that it is encoded in binary:

\[17 = \underbrace{1.0001}_{\text{significand}}\times {\underbrace{2}_{\text{base}}}^{\overbrace{4}^{exponent}}\]

The sign, significand, and exponent are all contained within the 64 bits.

By Codekaizen (Own work) [GFDL or CC BY-SA 4.0-3.0-2.5-2.0-1.0], via Wikimedia Commons

Because only a fixed number of bits are used, most real numbers cannot be represented exactly in a computer.

Another way of saying this is that, usually, a floating point number is an approximation of some particular real number.

Generally when we try to store a real number in a computer, what we wind up storing is the closest floating point number that the computer can represent.

The Relative Error of a Real Number stored in a Computer

Note

You can experiment with floating point representations to see how errors arise using this interactive tool.

The way to think about working with floating point (in fact, how the hardware actually does it) is:

1. Represent each input as the nearest representable floating point number.

2. Compute the result exactly from the floating point representations.

3. Return the nearest representable floating point number to the result.

What does “nearest” mean? Long story short, it means “round to the nearest representable value.”

Let’s say we have a particular real number \(r\) and we represent it as a floating point value \(f\).

Then \(r = f + \epsilon\) where \(\epsilon\) is the amount that \(r\) was rounded when represented as \(f\).

So \(\epsilon\) is the difference between the value we want, and the value we get.

How big can this difference be? Let’s say \(f\) is

\[f = \underbrace{1.010...01}_\text{53 bits}\times 2^n\]

Then \(|\epsilon|\) must be smaller than

\[|\epsilon| < \underbrace{0.000...01}_\text{53 bits}\times 2^n.\]

So as a relative error,

\[ \text{relative error} = \frac{|\epsilon|}{f} < \frac{{0.000...01}\times 2^n}{\underbrace{1.000...00}_\text{53 bits}\times 2^n} = 2^{-52} \approx 10^{-16}\]

This value \(10^{-16}\) is an important one to remember.

It is approximately the relative error that can be introduced any time a real number is stored in a computer.

Another way of thinking about this is that you only have about 16 digits of accuracy in a floating point number.

Implications of Representation Error

Problems arise when we work with floating point numbers and confuse them with real numbers.

It is important to remember that most of the time we are not storing the real number exactly, but only a floating point number that is close to it.

Let’s look at some examples. First:

\[ \left( \frac{1}{8} \cdot 8 \right) - 1 \]

# ((1/8)*8)-1
a = 1/8
b = 8
c = 1
(a*b)-c

0.0

It turns out that 1/8, 8, and 1 can all be stored exactly in IEEE-754 floating point format.

So, we are

• storing the inputs exactly (1/8, 8 and 1)

• computing the results exactly (by definition of IEEE-754), yielding \((1/8) \cdot 8 = 1\)

• and representing the result exactly (zero)

OK, here is another example:

\[ \left( \frac{1}{7} \cdot 7 \right) - 1 \]

# ((1/7)*7)-1
a = 1/7
b = 7
c = 1
a * b - c

0.0

Here the situation is different.

1/7 can not be stored exactly in IEEE-754 floating point format.

In binary, 1/7 is \(0.001\overline{001}\), an infinitely repeating pattern that obviously cannot be represented as a finite sequence of bits.

Nonetheless, the computation \((1/7) \cdot 7\) still yields exactly 1.0.

Why? Because the rounding of \(0.001\overline{001}\) to its closest floating point representation, when multiplied by 7, yields a value whose closest floating point representation is 1.0.

Now, let’s do something that seems very similar:

\[ \left( \frac{1}{70} \cdot 7 \right) - 0.1 \]

a = 1/70
b = 7
c = 0.1
a * b - c

-1.3877787807814457e-17

In this case, both 1/70 and 0.1 cannot be stored exactly.

More importantly, the process of rounding 1/70 to its closest floating point representation, then multiplying by 7, yields a number whose closest floating point representation is not 0.1

However, that floating point representation is very close to 0.1.

Let’s look at the difference: -1.3877787807814457e-17.

This is about \(-1 \cdot 10^{-17}\).

In other words, about -0.00000000000000001

Compared to 0.1, this is a very small number. The relative error is about:

\[ \frac{|-0.00000000000000001|}{0.1} \]

which is about \(10^{-16}.\)

This suggests that when a floating point calculation is not exact, the error (in a relative sense) is usually very small.

Notice also that in our example the size of the relative error is about \(10^{-16}\).

Recall that the significand in IEEE-754 uses 52 bits.

Now, note that \(2^{-52} \approx 10^{-16}\).

There’s our “sixteen digits of accuracy” principle again.

Special Values

There are three kinds of special values defined by IEEE-754:

1. NaN, which means “Not a Number”

2. Infinity – both positive and negative

3. Zero – both positive and negative.

NaN and Inf behave about as you’d expect.

If you get one of these values in a computation you should be able to reason about how it happened. Note that these are values, and can be assigned to variables.

np.sqrt(-1)

/var/folders/y0/f8_7klyx3sjbkw2pj03bnj040000gn/T/ipykernel_63587/3438155168.py:1: RuntimeWarning: invalid value encountered in sqrt
  np.sqrt(-1)

nan

var = np.log(0)
var

/var/folders/y0/f8_7klyx3sjbkw2pj03bnj040000gn/T/ipykernel_63587/329155313.py:1: RuntimeWarning: divide by zero encountered in log
  var = np.log(0)

-inf

1/var

-0.0

As far as we are concerned, there is no difference between positive and negative zero. You can ignore the minus sign in front of a negative zero. (If you are curious why there is a negative zero, see the online notes.)

Note

The reason for having a negative and positive zero is the following.

Remember that, due to the limitations of floating point representation, we can only store the nearest representable number to the one we’d like to store.

So, let’s say we try to store a number \(x\) that is very close to zero. To be specific, let \(|x| < 2.2 \times 10^{-308}\). Then the closest floating point representation is zero, so that is what is stored. This is known as “underflow”.

But … the number \(x\) that we were trying to store could have been positive or negative. So the standard defines a positive and negative zero. The sign of zero tells us when underflow occurred, “which direction” the underflow came from.

This can be useful in some numerical algorithms.

var = np.nan
var + 7

nan

var = np.inf
var + 7

inf

Mathematical Computation vs. Mechanical Computation

In a mathematical theorem, working with (idealized) numbers, it is always true that:

If

\[c = 1/a\]

then

\[abc = b.\]

In other words,

\[(ab)/a = b.\]

Let’s test whether this is always true in actual computation.

a = 7
b = 1/10
c = 1/a
a*c*b

0.1

b*c*a

0.09999999999999999

a*c*b == b*c*a

False

Here is another example:

0.1 + 0.1 + 0.1

0.30000000000000004

3 * (0.1) - 0.3

5.551115123125783e-17

What does all this mean for us in practice?

I will now give you three principles to keep in mind when computing with floating point numbers.

Principle 1: Do not compare floating point numbers for equality

Two floating point computations that should yield the same result mathematically, may not do so due to rounding error.

However, in general, if two numbers should be equal, the relative error of the difference in the floating point should be small.

So, instead of asking whether two floating numbers are equal, we should ask whether the relative error of their difference is small.

r1 = a * b * c
r2 = b * c * a
np.abs(r1-r2)/r1

1.3877787807814457e-16

np.finfo('float')

finfo(resolution=1e-15, min=-1.7976931348623157e+308, max=1.7976931348623157e+308, dtype=float64)

print(r1 == r2)

False

print(np.abs(r1 -  r2)/np.max([r1, r2]) < np.finfo('float').resolution)

True

This test is needed often enough that numpy has a function that implements it:

np.isclose(r1, r2)

True

So another way to state Rule 1 for our purposes is:

… always use np.isclose() to compare floating point numbers for equality!

Next, we will generalize this idea a bit:

beyond the fact that numbers that should be equal, may not be in practice,

we can also observe that it can be hard to be accurate about the difference between two numbers that are nearly equal. This leads to the next two principles.

Principle 2: Beware of ill-conditioned problems

An ill-conditioned problem is one in which the outputs depend in a very sensitive manner on the inputs.

That is, a small change in the inputs can yield a very large change in the outputs.

The simplest example is computing \(1/(a-b)\).

print(f'r1 is {r1}')
print(f'r2 is very close to r1')
r3 = r1 + 0.0001
print(f'r3 is 0.1001')

r1 is 0.1
r2 is very close to r1
r3 is 0.1001

Let’s look at

\[ \frac{1}{r1 - r2} \text{ versus } \frac{1}{r3-r2} \]

print(f'1/(r1 - r2) = {1/(r1 - r2)}')
print(f'1/(r3 - r2) = {1/(r3 - r2)}')

1/(r1 - r2) = 7.205759403792794e+16
1/(r3 - r2) = 9999.999999998327

If \(a\) is close to \(b\), small changes in either make a big difference in the output.

Because the inputs to your problem may not be exact, if the problem is ill-conditioned, the outputs may be wrong by a large amount.

Later on we will see that the notion of ill-conditioning applies to matrix problems too, and in particular comes up when we solve certain problems involving matrices.

Principle 3: Relative error can be magnified during subtractions

Two numbers, each with small relative error, can yield a value with large relative error if subtracted.

Let’s say we represent a = 1.2345 as 1.2345002 – the relative error is 0.0000002.

Let’s say we represent b = 1.234 as 1.2340001 – the relative error is 0.0000001.

Now, subtract a - b: the result is .0005001.

What is the relative error? 0.005001 - 0.005 / 0.005 = 0.0002

The relative error of the result is 1000 times larger than the relative error of the inputs.

Here’s an example in practice:

a = 1.23456789
b = 1.2345678
print(0.00000009)
print(a-b)

9e-08
8.999999989711682e-08

print(np.abs(a-b-0.00000009)/ 0.00000009)

1.1431464011915431e-09

We know the relative error in the inputs is on the order of \(10^{-16}\), but the relative error of the output is on the order of \(10^{-9}\) – i.e., a million times larger.

Further Reading

• Further information about how Python handles issues around floating point is at Floating Point Arithmetic: Issues and Limitations.

• An excellent, in-depth introduction to floating point is What Every Computer Scientist Should Know About Floating-Point Arithmetic.
